QUPAQ | ANYTRAY Tray feeders
The ANYTRAY Portion-2-Pack system is designed for high volume batch production.
The ANYTRAY Portion-2-Pack 60 is an automatic tray filling system that feeds portions/products from the portioning system, fills the portions/product into trays and delivers them to the packaging machine at a speed of up to 60 trays per minute.
It includes an intelligent electrical control system and allows manual tray refilling in the ANYTRAY Denester.
See next all the models with their features.
Contact us to receive a customized quote for your needs.
Tel. +35722526262
email: finde.trading@cytanet.com.cy
Description
 |  |  | |
| Model | ANYTRAY Portion-2-Pack 60 | ANYTRAY Portion-2-Pack 75-90 | ANYTRAY Portion-2-Pack 135 |
| Productivity | 60 trays/minute | 90 trays/minute | 135 trays/minute |
| Maximum tray size | 325 mm | 325 mm | 325 mm |
| Maximum tray width | 265 mm | 265 mm | 265 mm |
| Entrance height | 800 mm ± 150 mm | 1000 mm ± 100 mm | 800 mm ± 150 mm |
| Output height | 800 mm ± 150 mm | 898 mm ± 100 mm | 800 mm ± 150 mm |
| Provided by | 3 x 400 VAC + N + PE | 3 x 400 VAC + N + PE | 3 x 400 VAC + N + PE |
| Air consumption | 200L (120 trays/minute) | 300L (120 trays/minute) | 200L (120 trays/minute) |
| Air supply | 6 bar | 6 bar | 6 bar |
| Humidity | 10% – 90% | 10% – 90% | 6 bar |
| Construction | Stainless steel ANSI304 | Stainless steel ANSI304 | Stainless steel ANSI304 |
| Engine weight | 180 kg | 400 kg | 450 kg |
Additional information
| Supplier | QUPAQ |
|---|
